Ceiling Concealed Ducted Type Air Conditioner Only Cooling

Ceiling Concealed Ducted Type Air Conditioner Only Cooling

AIRMYTH floor and ceiling type air conditioners is perfect air conditioning solutions because they allow installation as a floor console, also in a suspended ceiling or semi-concealed in the ceiling.

Product Details

'Thoughtful, comprehensive and timely service' is our eternal commitment! We can quickly respond to the market and produce Single Deflection Grille, Return Grille, High ESP Ducted Fan Coil Unit that meet the needs of different customer groups. Our design always starts from the details to meet the requirements of every detail in use. In the design, we try to think more, understand more and do more. We create a brand with integrity and establish a foundation with concentration. Our company has a sound after-sales service network organization.

Floor and Ceiling air conditioner

AIRMYTH floor and ceiling type air conditioners is perfect air conditioning solutions because they allow installation as a floor console, also in a suspended ceiling or semi-concealed in the ceiling. Air conditioners have high energy efficiency and have many additional features and modes to make it easier for use. AIRMYTH Floor and ceiling air conditioner adopts electrical expansion valve, ensuring precise flow control, lower modulation noise when EXV is operating. Low noise operations; minimum 36 dB(A). Smoother airflow and less turbulence due to the multi-blade fan and the air guide design. The slim and sleek structure design ensures easy installation. It can be installed into a corner of the ceiling even if the ceiling is very narrow.Due to easy installation, Spave saving and cost saving, floor and ceiling air conditioners are widely used in restarants,small hotels,school,stations,gyms and offices.

1


1.The dual-purpose floor & ceiling AC with a stylish appearance design, and can be easily integrated into various decoration styles to meet the aesthetic needs.

The product can also be installed flexibly according to the actual needs of users. It can be suspended on the ceiling or on the ground. It can be directly exposed and hoisted in places without ceiling decoration.

2


2.Space saving.

For commercial sites, it is necessary to save operating costs as much as possible to maximize benefits. Compared with traditional air conditioners, the floor & ceiling AC not only saves floor space, but also saves the overall ceiling decoration cost. It meets the demand for efficient use of space at high prices and brings savings to users.

3


3.Water pump can be customized.The pumping head is up to 700mm.

6


4.Auto swing function,built- in two louver motor,vertical and horizontal air-flow adjustment.


ModelAMFC-18CAMFC-24CAMFC-36CAMFC-48CAMFC-60C
Indoor power supplyV/Ph/Hz220~240V/1Ph/50Hz220~240V/1Ph/50Hz220~240V/1Ph/50Hz220~240V/1Ph/50Hz220~240V/1Ph/50Hz
CoolingCapacityBtu/h1800024000360004800060000
KW5.37.110.51416
InputW130150300260260
RatedcurrentA0.30.71.41.151.15
EERW/W2.612.782.622.662.68
Max. input consumptionW2500200400300300
Max. currentA12.61.11.91.351.35
Indoor air flow(High speed)m3/h7901300170023002300
Indoor noise leveldB(A)44~5239~4844~5257~4857~48
Indoor unitDimension(W*H*D)mm880×635×2051245×680×2471245×680×2471670×680×2471670×680×247
Packing(W*H*D)mm970×725×3011325×770×3251325×770×3251750×770×3251750×770×325
Net/Gross weightkg30/3535/4137/4347/5447/54
Max pressure
MPa4.04.04.04.54.5
Refrigerant typeR410AR410AR410AR410AR410A
Refrigerant pipingLiquid side/Gas sidemmΦ6.35/Φ12.7Φ9.52/Φ15.88Φ9.52/Φ19.05Φ9.52/Φ19.05Φ9.52/Φ19.05
Drainage pipemm2525252525
Standard controllerStandard for remote controller(wired controller for option)
Operation temp
°C16~3216~3216~3216~3216~32
Ambient temp°C18~4318~4318~4318~4318~43
Application aream220-3528-5040-7055~9560~105
Stuffing Quantity(20'/40'/40'HQ)set132/270/30675/165/18975/165/18960/120/12360/120/123


We will continue to provide our customers with the best products at the best prices, and we are ready to provide technical services for casting and finishing to meet the ever-changing needs of our Ceiling Concealed Ducted Type Air Conditioner Only Cooling. We combine originality, rich expertise and special equipment to provide you with the exact products you need。 We try to improve management techniques and adjust resources to meet customer needs and internationalize our products and services.
